PRODUCT SUMMARY

The Benner-Nawman 14326W-SM surface mount enclosure is a fully enclosed exterior service box built for durable utility installations. Constructed from 16-gauge zinc-coated steel with a powder-coat tan finish, it features a reinforced hinged door with a recessed hex latch. The enclosure is UL listed and designed to NEMA 3R requirements for outdoor applications.

Features
  • Fully enclosed exterior service box
  • Constructed of 16 gauge zinc-coated steel with powder-coat tan finish
  • 16 gauge reinforced hinged door with 7/16" recessed hex latch
  • Box weight is 37 lbs.
  • UL listed (UL 1863); designed to NEMA 3R
14326W-SM Service Box Includes:
  • Enclosure w/ hinged door
  • 4-position #4-14 wire ground bar
  • 1/2" plywood back board for mounting utility equipment
  • 2 knockouts for 3/4" - 1-3/4" conduit; 3 knockouts for 3/4" - 1-1/4" conduit
Downloads

Specification Sheet



Bimobject - Benner Nawman
 Close

BUY ONLINE | Available Now from these Distributors

BN Product
  • CCI Logo
  • Platt Electric Logo - Benner-Nawman
  • Graybar Distributor - Benner-Nawman
  • Codale distributor logo
Enclosure Type Exterior, Surface Mount
Model # 14326W-SM
Dimensions 14" (W) x 32" (H) x 6" (D)
Box Weight 37 lbs.
Certifications UL listed (UL1863); NEMA 3R
Total Knockouts 5
