24268W-UL Surface-Mount-Enclosure

Benner-Nawman 24268W-UL surface mount enclosure
Front
Hinged Door and Protective Edges
Dimensions and Knockout Diagram
Benner-Nawman 24268W-UL surface mount enclosure

PRODUCT SUMMARY

The Benner-Nawman 24268W-UL surface mount enclosure is a fully enclosed exterior service box designed for durable utility and communications installations. Constructed from 16-gauge zinc-coated steel with a powder-coat tan finish, it features a reinforced hinged door with a recessed hex latch. This UL-listed enclosure is designed to NEMA 3R requirements for reliable exterior use.

Features
  • Fully enclosed exterior service box
  • Constructed of 16 gauge zinc-coated steel with powder-coat tan finish
  • 16 gauge reinforced hinged door with 7/16" recessed hex latch
  • "Communications" embossed
  • Box weight is 53 lbs.  | 24" W x 26" H x 8" D
  • UL listed (UL 1863); designed to NEMA 3R
24268W-SM Service Box Includes:
  • Enclosure w/ hinged door
  • 4-position #4-14 wire ground bar
  • 3/4" plywood back board for mounting utility equipment
  • 2 knockouts for 3/4" - 2" conduit; 10 knockouts for 3/4" - 1-1/2" conduit
Downloads

Specification Sheet



Bimobject - Benner Nawman
 Close

BUY ONLINE | Available Now from these Distributors

BN Product
  • CCI Logo
  • Platt Electric Logo - Benner-Nawman
  • Gexpro logo
  • Graybar Distributor - Benner-Nawman
  • CED Chico
  • CED EL Centro
  • Amazon Logo
Enclosure Type Exterior, Surface-Mount
Model # 24268W-UL
Dimensions 24" x 26" x 8"
Box Weight 53 lbs.
Certifications UL listed (UL 1863); NEMA 3R
Total Knockouts 12
