36-Inch Series Surface-Mount Enclosures
Front
Dimensions & Knockouts
PRODUCT SUMMARY
Features
- Two Models:
- 36368W-UL: 36" W x 36" H x 8" D
- 36369W-UL: 36" W x 36" H x 9" D
- Fully enclosed exterior service boxes
- Constructed of 14 gauge zinc-coated steel with powder-coat tan finish
- 14 gauge reinforced hinged door with 7/16" recessed hex latch
- "Communications" embossed
- Box weight is 115 lbs. (36368W-UL) | 119 lbs. (36369W-UL)
- UL listed (UL 1863); designed to NEMA 3R
36" Service Boxes Include:
- Enclosure w/ hinged door
- 3/4" plywood back board for mounting utility equipment
- 4-position #4-14 ground bar
- 12 Total Knockouts
Product Links
Close
BUY ONLINE | Available Now from these Distributors
| Enclosure Type | Exterior, Surface-Mount |
| Model #s (Dimensions/Box Weight) | 36368W-UL: 36" W x 36" H x 8" D | 115 lbs. |
| 36369W-UL: 36" W x 36" H x 9" D | 119 lbs. | |
| Knockouts | 36368W-UL: 2 knockouts 2-1/2" to 3-1/2" (for 2" to 3" conduit) & 10 knockouts 1-1/8" to 1-3/4" (for 1" to 1-1/2" conduit) |
| 36369W-UL: 2 knockouts 2-1/2" to 3-1/2" (for 2" to 3" conduit) & 8 knockouts 1-3/8" to 1-3/4" (for 1" to 1-1/2" conduit) | |
| Certifications | UL listed (UL 1863); designed to NEMA 3R |
